What Is Needed During Onboarding
Hopefully, we were able to do our complimentary demo with you using your location and your CAD file, but if not, here is a description of what we will be looking for when it comes time to join the Southeast Geospatial family.
A friction-free kickoff starts with two CAD files from your engineering team.
1. Overall Subdivision Design
What it is: A DWG/DXF showing lot boundaries, road centerlines, easements, utilities, and any phasing lines.
Why we need it:
- Flight-path precision – Defines the horizontal extents, allowing us to program efficient, FAA-compliant flight lines.
- Ground-control accuracy – Pinpoints where RTK targets should go to tighten horizontal error to sub-inch levels.
- Data fusion – Acts as the reference layer for all orthomosaics, LiDAR clouds, and surface models.
If the file isn’t perfect:
Mis-named layers, duplicate linework, or missing coordinate systems? We create a cleaned “working copy”—layer-purged, geo-referenced, and ready for Civil 3D, OpenRoads, or GIS. No invoices, no delays.
2. Approved Grade Plan
What it is: A CAD file containing both existing ground and proposed finish grades—contours, spot elevations, or separate TIN surfaces.
Why we need it:
- Cut/Fill analytics – Overlaying our gathered surface on your proposed grades yields instant earth-volume calcs and dirt-balance checks.
- Compliance checkpoints – Re-flights compare as-built terrain to design, flagging out-of-tolerance areas before they snowball.
- Drainage verification – Lets us re-run hydrology after every phase to catch swale or pond issues early.
If the file isn’t perfect:
Broken surface boundaries, missing breaklines, stray contours? We rebuild a second, QA-vetted surface so analytics run smoothly—again, at zero cost.
The Big Picture: Turning Data Into Decisions
| Workflow Stage | What We Do With Your CAD | Value to Your Team |
|---|---|---|
| Pre-Flight | Optimize grid, set RTK control, define AOI | Faster mobilization & regulatory compliance |
| CAD Optimization | Purge, re-layer, geo-reference, rebuild surfaces | Clean “working copy” returned to you FREE |
| Processing | Snap LiDAR/orthos to design coordinates | Sub-inch horizontal & vertical accuracy |
| Analytics | Auto-generate cut/fill maps, slope heatmaps, drainage models | Data-driven dirt balancing & grading checks |
| Reporting | Publish web viewer & export CAD-ready surfaces | One-click import back into Civil 3D, MicroStation, etc. |
Why The Free CAD Tuneup Matters
| Problem We Fix | Hidden Cost You Avoid |
|---|---|
| Misaligned coordinate system | Hours lost re-projecting every aerial deliverable |
| Duplicate or phantom layers | Bloated file sizes that crash Civil 3D |
| Broken TIN edges or gaps | Inaccurate earth-work numbers and bidding errors |
| Unnamed blocks and loose annotation | Confusion for field crews & surveyors |
Local expertise. Faith-driven values. Data that moves dirt. That’s the Southeast Geospatial difference.
Our philosophy is simple: Great data in leads to great insights out. By delivering a clean, ready-to-use CAD base—whether we receive it that way or make it that way—you get:
- Accelerated timelines – First flight within 24 hrs of file receipt.
- Guaranteed accuracy – Grade-to-design checks within ±0.10 ft.
- Risk reduction – Documented proof that grades, slopes & drainage match plans before hand-off.
Ready to Get Started?
Email your subdivision design and grade plan to [email protected] (DWG or DXF, coordinate system noted). If the files need TLC, we’ll return a perfected copy and hit the air within 48 hours—no extra fee, no hidden clauses.
